High Throughput Planetary Ball Mill w/ 4 -16 SS Milling Jars (10 -100ml Per Jar) - MSK-SFM-13S

High Throughput Planetary Ball Mill w/ 4 -16 SS Milling Jars (10 -100ml Per Jar) - MSK-SFM-13S

MSK-SFM-13S is a benchtop high throughput planetary ball mill designed to achieve the most efficient milling and fine grinding quality. 4 grinding stations with 4 cavity SS milling jars allow you to prepare up to 16 different materials (alloys, ceramics, chemical products, polymer composites, metal oxides, minerals, etc) in an efficient way. This is an ideal solution whenever high throughput material grinding/mixing is needed. It also can be used as four tanks (4x 10 ml) planetary mill removing 10 ml small tank.


SPECIFICATIONS

Features


  • High throughput processing is feasible thanks to the 4-cavity SS jar. Up to 16 different materials can be processed at the same time with 4 jars placed in position. Please click the bottom left image to see the details.
  • Bench-top compact design with 4 Grinding Stations.
  • Large touch screen controller allows easy programming for multi-step speed-up/down milling/grinding, rotate direction, timing control, and cycling
  • Efficient grinding benefits from the high centrifugal force and pulverization energy
  • Suitable for mechanical alloying, mixing, homogenizing, pulverizing
  • Minimum output granularity can be as small as 0.1 um

Working Voltage
  • 208 - 240V AC (single-phase), 50/60 Hz
  • 220V AC Power plug is not included. Please click here to order the plug.
  • For operation under 110V, please use > 1000W transformer (click here to order)
  • Power: 550W max.
Speed
  • Speed adjustable by tuning the frequency output to the AC motor
  • Revolution: Max.324 RPM, Min: 30 RPM
  • Mixing tank self-rotation: Max. 648 RPM Min: 60 RPM
Speed Ratio Revolution:Self-rotation = 1:2
Touch Screen Control
  • Digital display and inputs for speed and time
  • Up to 10 recipes can be stored
  • Max. 5 segments speed control per recipe, up to 10 Cycles
  • Max. time for each segment is 99 hours 59 minutes 59 seconds
  • Rotation direction selectable, clockwise-anticlockwise
Material Feed Size Crispy materials< 10mm (Others<3mm)
Material Output Size
  • Wet Milling < 1um average
  • Dry milling < 20um average
Note: The output granularity is dependent on the material physical properties such as size, milling media and processing time. Minimum granularity can be as small as 0.1 um according to the customer's feedback.

Milling Jars
  • Four sets of 4 cavity SS jars (10ml/cavity) are included, which can mill 16 samples per batch. Pic 1
  • Four sets of SS milling ball combo are included. Please click the pic in below to order spare balls. Pic. 2
  • Four jar holders can accommodate the single cavity jars, such as SS jar (Pic 4), vacuum jar. (pic. 5), Alumina Jar (Pic.6) Tungsten jars Pic. 3)
  • We provide a wide range of jar/ball materials for contamination-free processes, such as Nylon, Alumina, Zirconia, agate...Please contact us for more details.

4 cavity SS jar (included)
Pic. 1

SS Milling Balls ( Included)
Pic. 2

WC Jar
Pic 3)

100ml SS Jar
Pic. 4

Vacuum. Jar (Pic. 5)
Noise Level 55~70 decibel
Holding Fixtures
  • Four sets of holding fixtures are included
  • Easy to tight for max. jar securing. Can hold jars with height up to 80mm
Compliance
  • CE Certified
  • NRTL certification is available at extra cost

Application Notes
  • SS304 mixing jar is suitable for grinding various metal materials
  • For milling the oxide material, please choose alumina/Nylon jars and zirconia media. DO NOT USE stainless steel balls in Alumina jars.
  • Must place 4 jars or 2 in symmetrical with similar weight in the ball mill to keep balance during rotation, If using one jar, you must put another jar with the same weight in a symmetrical position. Otherwise, unbalance rotation, especially one jar, may damage the machine.
  • Please consider our SYU-3 Ultrasonic Filtration System for filtering the product
  • Please click underline to learn Centrifugal Force calculation.

Max. time for each segment is 99 hours 59 minutes 59 seconds
