Crystal Grower By Vacuum Levitation Melting up to 2000ºC - SKJ-LCZ

MTI is designing and developing a special CZ crystal grower from vacuum levitation melting up to 2000ºC. The system includes a high-frequency induction heating supply, high vacuum chamber, water cold copper crucible for levitation melting and a precision pulling mechanism. Levitation melting avoids the contamination of the sample from the crucible and may produce a high-purity crystal for metallic alloys

Basic Specifications:

Structure of Grower	40KW RF Induction power source for levitation melting Special designed water-cooled copper crucible for 60 g max. metal melt levitation up to 2000ºC Vacuum Chamber, which can reach 10-6 torr using a turbopump system Precision pulling system with a rotary rod with a speed of 0.1 mm/h - 24 mm/h
RF Induction Power Source	Input power 40 kW max. Frequency 80-200KHz Current 10-100A Input Voltage: 200V +/-10% , Three-phase, 50/60Hz Water Cooling Pressure 0.2MPa Water flow: 10L/min
Water Cold Copper Crucible	Crucible size: ID 35mm, Depth: 60mm Melting Capability: 60g Max. Water flow requied 58L/min
Pulling Mechanism	Pulling Speed: 0.1-24mm/h Pulling Rod Rotation Speed 0.03-50r/min Pulling travel distance: 250 mm Faster travel: Manual operation Optional: A cold water pulling rod is available upon request at extra cost.
Vacuum Chamber & Vacuum Pump	Made of SS 304 with water cooling jacket Vacuum Chamber size: Φ400x 40 D mm Quartz Widow: Φ300mm Two KF-25 ports for gas inlet and outlet Vacuum Level: 10-6 Torr by turbopump Vacuum Pump: high-speed turbopump with 700L/S
Water Cooling	> 110 L/Minute at 30 °C recirculating water flow is required The water chiller is not included. Please click the picture left to order
Compliance	CE certified NRTL or CSA certification is available upon request at an extra cost Assembling and quality controlled in the USA
